Thermal Pad
1.5W/mK (VT-TP-15)
Physical features
| Content | Standard | Unit | Value |
|---|---|---|---|
| Color | White | ||
| Thickness | mm | 0.5 – 3.0 | |
| Specific gravity | ASTM D792 | g/cm3 | > 2.4 |
Thermal features
| Content | Standard | Unit | Value |
|---|---|---|---|
| Flame Rating | UL94 | Class | V-0 |
| Thermal Conductivity |
ASTM D792 | W/mK | > 1.5 |
Mechanical features
| Content | Standard | Unit | Value |
|---|---|---|---|
| Hardness | ASTM D2240 | Shore00 | 50-90 |
| Tensile strength |
ASTM D638 | N/mm2 | > 0.7 |
Electrical features
| Content | Standard | Unit | Value |
|---|---|---|---|
| Dielectric Breakdown Voltage |
ASTM D149 | KV/mm | > 16 |
| Volume Resistivity |
ASTM D257 | Ω·cm | > 1012 |
Thermal Conductivity
Thermal Resistance
| BLT [μm] | Rth [K/W] |
|---|---|
| 500 | 1.675275 |
| 750 | 2.061275 |
| 1000 | 2.447275 |
| 1250 | 2.833275 |
| 1500 | 3.219275 |
| 1750 | 3.605275 |
| 2000 | 3.991275 |
Thermal Conductivity
| - K = 2.09 W/(mK) |
|---|
| - Regression equation: -0.6224 + 0.0037 x |
| - R2 = 0.998 |
| - σK = ±0.073 W/(mK) |
| - σRth = ±0.013 K/W |
3.0W/mK (VT-TP-30)
Physical features
| Content | Standard | Unit | Value |
|---|---|---|---|
| Color | Blue | ||
| Thickness | mm | 0.5 – 3.0 | |
| Specific gravity | ASTM D792 | g/cm3 | > 2.7 |
Thermal features
| Content | Standard | Unit | Value |
|---|---|---|---|
| Flame Rating | UL94 | Class | V-0 |
| Thermal Conductivity |
ASTM D5470 | W/mK | > 3.0 |
Mechanical features
| Content | Standard | Unit | Value |
|---|---|---|---|
| Hardness | ASTM D2240 | Shore00 | 50-90 |
| Tensile strength |
ASTM D638 | N/mm2 | > 0.3 |
Electrical features
| Content | Standard | Unit | Value |
|---|---|---|---|
| Dielectric Breakdown Voltage |
ASTM D149 | KV/mm | > 16 |
| Volume Resistivity |
ASTM D257 | Ω·cm | > 1012 |
Thermal Conductivity
Thermal Resistance
| BLT [μm] | Rth [K/W] |
|---|---|
| 500 | 2.750555 |
| 750 | 3.188305 |
| 1000 | 3.626055 |
| 1250 | 4.063805 |
| 1500 | 4.501555 |
| 1750 | 4.939305 |
| 2000 | 5.377055 |
Thermal Conductivity
| - K = 3.86 W/(mK) |
|---|
| - Regression equation: 1.7702 + 0.0020 x |
| - R2 = 0.998 |
| - σK = ±0.112 W/(mK) |
| - σRth = ±0.026 K/W |
5.0W/mK (VT-TP-50)
Physical features
| Content | Standard | Unit | Value |
|---|---|---|---|
| Color | Pink | ||
| Thickness | mm | 0.5 – 3.0 | |
| Specific gravity | ASTM D792 | g/cm3 | > 2.7 |
Thermal features
| Content | Standard | Unit | Value |
|---|---|---|---|
| Flame Rating | UL94 | Class | V-0 |
| Thermal Conductivity |
ASTM D5470 | W/mK | > 3.0 |
Mechanical features
| Content | Standard | Unit | Value |
|---|---|---|---|
| Hardness | ASTM D2240 | Shore00 | 50-90 |
| Tensile strength |
ASTM D638 | N/mm2 | > 0.4 |
Electrical features
| Content | Standard | Unit | Value |
|---|---|---|---|
| Dielectric Breakdown Voltage |
ASTM D149 | KV/mm | > 16 |
| Volume Resistivity |
ASTM D257 | Ω·cm | > 1012 |
- * 상기 수치는 표준시험방법에 의한 대표적인 수치이며, 특정용도에의 성능을 보증하는 자료는 아닙니다.
- * 상기 수치는 사전통보 없이 제품의 품질 개선으로 인하여 변경될 수 있습니다.
- * 전자부품용 RoHS 6대 환경유해물질 인증
Thermal Conductivity
Thermal Resistance
| BLT [μm] | Rth [K/W] |
|---|---|
| 500 | 1.675275 |
| 750 | 2.061275 |
| 1000 | 2.447275 |
| 1250 | 2.833275 |
| 1500 | 3.219275 |
| 1750 | 3.605275 |
| 2000 | 3.991275 |
Thermal Conductivity
| - K = 5.03 W/(mK) |
|---|
| - Regression equation: 1.4033 + 0.0015 x |
| - R2 = 1.000 |
| - σK = ±0.039 W/(mK) |
| - σRth = ±0.005 K/W |
Applications
-
Smart TV
Monitor -
Labtop`
-
STB·DVR
PVR -
Automotive
parts -
Mobiles -
LED light -
PCB -
Audio,
DVD, RF
-
ThermalPad
applications -
ThermalPad for
electric parts -
ThermalPad for
LED light -
ThermalPad for EV
vehicles -
-
